Features:
- Features an advanced solid dielectric and large-area PTFE liquid junction, preventing clogging and ensuring easy maintenance.
- Equipped with a long-distance reference diffusion path, significantly extending electrode lifespan even in harsh and demanding environments.
- Constructed with a durable PPS/PC shell and integrated 3/4″ NPT threads (top and bottom) for easy side or vertical installation without the need for additional sheaths, reducing installation costs.
- Built-in high-quality, low-noise cable allows for stable signal transmission over distances greater than 40 meters, minimizing interference and ensuring reliable data.
- Operates without the need for supplemental electrolyte, reducing maintenance frequency and simplifying routine servicing.
- Delivers high measurement accuracy, fast response time, and excellent repeatability, even under variable process conditions.
- Incorporates a silver ion (Ag/AgCl) reference electrode for stable and consistent performance.
- Designed for flexible installation directly into reaction tanks or pipelines, supporting both vertical and horizontal mounting.
Specifications:
- Range: 0-14 pH
- Cable: 5 m (16.4 ft)
- Material: Glass
- Temperature: 0-100℃ (32°F-212°F) with compensation
- Thread: PG13.5
Applications:
- Wastewater Treatment – Essential for continuously monitoring and controlling pH levels in municipal and industrial wastewater systems. Stable pH is critical for effective biological treatment, chemical dosing, and meeting environmental discharge regulations.
- Paper & Pulp Industry – Used to precisely control pH during pulp cooking, bleaching, and paper production. Maintaining the correct pH improves product quality, optimizes chemical usage, and reduces production costs.
- Textile & Dyeing Processes – Accurate pH control is vital during dyeing, finishing, and washing processes to achieve consistent color, fabric quality, and process efficiency. This sensor ensures stable readings even in harsh dyeing environments.
- Petrochemical Industry – Applied in process streams and wastewater treatment where pH stability is necessary to protect equipment from corrosion, maintain chemical balance, and ensure safe and efficient operations.
- Semiconductor & Electronics Manufacturing – Critical for maintaining the ultra-precise pH levels required for wafer cleaning, etching, and other sensitive processes. Accurate pH measurement directly affects product yield and quality.
- Biotechnology & Pharmaceutical Production – Ensures optimal pH conditions in fermentation, purification, and downstream processing stages, where even slight deviations can impact product purity, yield, and regulatory compliance.
