Specifications:Â
- Weighing capacity [Max]: 20 kg
- Measuring range force [Max] (N): 200 N
- Design: Tension-/compression rod
- Directions of force: tension, compression
- Measuring applications: force, mass
- Load cell – Combined error: 0.5%
- Load cell OIML class: G5
- Load cell – characteristic value – nominal: 1.5 mV/V
- IP protection – complete device: IP65
Applications:
- Tensile and Compressive Force Measurement: Ideal for applications requiring precise measurement of both tensile and compressive forces, such as in material testing and mechanical analysis.
- Mass Measurement: Suitable for high-precision weight measurement applications, including integration into weighing systems and scales.
- Force Test Stands: Commonly used in force test stands for quality control and research purposes, providing accurate force measurement capabilities.
