Specifications:
- Measuring range force [Max] (N): 500 N
- Readability force [d] (N): 0,1 N
- Tolerance (% of [Max]): 0,5%
- Measuring head measuring frequency: 2 kHz
- Supplied power supply: Accu & Power supply
- Memory function: Yes
- Statistic function: Yes
- Limit-setting function: Yes
- Hold function: Yes
- Peak function: Yes
- Dimensions completely mounted (W×D×H): 230×66×36 mm
- Net weight approx.: 10 kg
- Interfaces: RS-232 standard
Applications:
- Quality Control: Ensuring products meet required force specifications during manufacturing processes.
- Material Testing: Evaluating the mechanical properties of materials under stress or load.
- Assembly Line Operations: Measuring forces during the assembly or packaging processes to ensure proper tension or pressure.
- Engineering: Testing the load resistance of components like springs, cables, or adhesives.
- Calibration: Calibrating machines and instruments that depend on precise force measurements for their operations.
