Specifications:
- Generated force [Max]: 20 kN
- Traverse distance [Max]: 210 mm
- Type of drive: Stepper motor
- Length measuring device: Length measuring device with data interface
- Input voltage power supply / power [Max]: 230 V AC, 50 Hz
- Limit switch: Yes
- Repeat function: Yes
- Speed display: Yes
- Material housing: metal, lacquered
- Dimensions completely mounted (W×D×H): 400×250×1550 mm
- Transversal movement speed [Min]: 1 mm/min
- Transversal movement speed [Max]: 70 mm/min
Applications:
- Material Testing: Evaluating the tensile, compressive, and shear strength of various materials.
- Quality Control: Ensuring products meet strength and durability requirements for industry standards.
- Product Development: Testing prototypes and designs to verify performance under stress conditions.
- Manufacturing: Assessing components and finished products for structural integrity during production.
- Research: Supporting scientific investigations in material science, engineering, and mechanical studies.
