Features:
- Rechargeable battery for convenient cordless use
- Easy operation with four simple buttons
- Durable stainless steel weighing pan
- Handlebar frame and wheeled base for effortless mobility
- Color-coded keys for quick identification
- External calibration capability
- Robust four load cell design for accurate results
- Full-range tare function
- Bi-directional RS-232 interface for data communication
- Switchable units: kg, lb, oz, or lb & oz
- Hold function to retain readings
- Tare function for net weight measurement
- Large, easy-to-read backlit LCD display
- Operates on rechargeable battery or mains power
- Fully portable for flexible use
- Backed by a 3-year warranty
- Non-NTEP (Not legal for trade)
Specifications:
- Capacity: 75 lb, 615 lb, 330 lb, or 440 lb
- Readability: .02 lb, .05 lb, or 0.1 lb
- Platform Size: 19.7″ x 19.7″ (500 x 500 mm)
- Repeatability (S.D.): 50 g
- Linearity (±): 100 g
- Tare Range: Full range
- Applications: Standard weighing, dynamic/animal weighing, display hold
- Units: lb, kg, oz, lb-oz
- Stabilization Time: 2–3 seconds (typical)
- Calibration: External automatic calibration
- Display: 25 mm backlit LCD Power: 12 VAC, 500 mA adapter or internal rechargeable battery
- Overall Dimensions (W x D x H): 19.7″ x 19.7″ x 1.6″ (500 x 500 x 40 mm)
- Indicator Dimensions (W x D x H): 8.7″ x 3.7″ x 1.7″ (220 x 95 x 43 mm)
- Net Weight: 23.1 lb
- Interface: Bi-directional RS-232
- Humidity Range: Up to 90% RH (non-condensing)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
Models:
- CPWplus 35W: 75 lb / 35 kg capacity x0.02 lb / 10 g readability
- CPWplus 75W: 165 lb / 75 kg capacity x 0.05 lb / 0.02 kg readability
- CPWplus 150W: 330 lb / 150 kg capacity x0.1 lb / 0.05 kg readability
- CPWplus 200W: 440 lb / 200 kg capacity x0.1 lb / 0.05 kg readability
