Features:
- Quick Change Pressure Modules (30 seconds): Additel’s 151 pressure control modules can be installed or replaced within 30 seconds or less. Simply open the upper edge of the cabin to open. As the door opens, the controller will automatically release pressure, providing the safe removal and installation of the ADT151 modules. Additel offers various different pressure ranges for the ADT773 controller utilizing these easy to swap pressure modules.
- 20% Pressure Step within 10 seconds: In the process of efficient and fast-paced end-of-line testing and verification and calibration, companies have strict requirements on the speed of pressure controllers. ADT773 adopts professional control technology to effectively improve control speed and control stability. Air pressure controller: control response time (typical) ≤10S, control stability (typical) ≤±(0.001~0.003)
- Built-in pump: The Additel 773 comes with an integrated internal low-pressure pump which provides users with a turnkey solution for pressure calibration work. Additel pump designs are well known and dependable. Not only are the fast, but they also offer the best control and stability in their class. In fact, the automated pumps in other Additel models have revolutionized the industry.
- External Drive Valve Control: The ADT773 Controller provides valve control for up to 3 external valves. One of the channels is designated for us to control contamination prevention system (CPS), which helps to prevent media contamination. The remaining two channels can be used to control external vacuum pumps or external isolation valves for greater flexibility and compatibility for individual situations.
- Contamination Prevention System (CPS) Prolongs the Maintenance of the Controller: Calibration of DUT’s (devices under test) often introduces contaminates to a calibration system. Contaminates can cause restrictions in valves, lines and filters. Additel has included a turn-key solution with the ADT773 to help reduce these concerns and improve durability and dependability when calibrating customers devices. The use of an automatic fluid exhaust system and integration firmware to allow for purges between pressure cycles to further reduce the possibility of introducing contaminates into the system.
Specifications:
- Max Pressure Range[1]: 400 inH2O (14.5 psi, 1 bar)
- Min Pressure Range: -380 inH2O (-13.5 psi, -0.95 bar)
- Precison[2]: 0.015%FS (DP2-DP5) 0.025%FS (DP10-DP1K)
- Accuracy[3]: 0.05%FS (DP2-DP5) 0.02%FS (DP10-DP1K)
- Control Stability[4]:＜0.003%FS
- Control Response Time[5]:＜10 Seconds
- Pressure Type: Low Differential Pressure
- Internchangeable Pressure Module Bays: 2
- Max Pressure Control Range of Internal Module: (-400~400) inH2O / (-1~1) bar
- Min Pressure Control Range of Internal Module: (-1~1) inH2O / (-2.5~2.5) mbar
- Range Switching Mode: Fixed or Auto
- Supply Source: Built-in air pump
- Control Mode: Fast, standard or custom
- Maximum Overshoot:＜1%FS
- Maximum Load Volume: 500 mL
- Contamination Prevention System: (CPS) Optional
- Pressure Port6: mm Festo
- Port Filter[6]: Support
