Specifications:
- Measuring range force [Max] (N): 5 kN
- Readability force [d] (N): 1 N
- Tolerance (% of [Max]): 0.5%
- Measuring head measuring frequency: 2 kHz
- Number of platforms / channels: 1
- Supplied power supply: Accu & Power supply
- Rechargeable battery: 8.4V / 1200mAh Ni-Hi
- Memory function: ✓
- Statistic function: ✓
- Limit-setting function: ✓
- Hold function: ✓
- Peak function: ✓
- Dimensions completely mounted (W×D×H): 320×190×166 mm
- Net weight approx.: 1.8 kg
- Interfaces: RS-232 standard
- Cable length: 3 m
Applications:
- Quality Control & Testing – Ensuring product strength and durability in manufacturing.
- Material Testing – Measuring tensile and compressive forces in metals, plastics, and other materials.
- Automotive & Aerospace – Testing components, fasteners, and mechanical assemblies for safety and performance.
- Electronics & Small Parts Manufacturing – Measuring forces in delicate components such as connectors and switches.
- Medical & Biomechanics – Evaluating force levels in medical devices, prosthetics, and rehabilitation research.
- Industrial Equipment Maintenance – Checking tension and compression in machinery and tools.
- Research & Development – Conducting force analysis for new product development and material studies.
- Construction & Engineering – Measuring load forces in structural components and materials.
- Textile & Packaging Industry – Testing tear resistance, adhesion strength, and material elasticity.
- Education & Training – Teaching force measurement principles in technical and engineering programs.
