Specifications:
- Hardness scales: Shore D
- Measuring range Shore [Max]: 100 HD
- Readability Shore [d]: 1 HD
- Tolerance (% of [Max]): 3%
- Scale – Display type: Analogue
- Material housing: Metal
- Measuring probe diameter: 18 mm
- Test force Hardness measurement: 10 N
- Product family: HB
- GTIN/EAN number: 4045761140189
Applications:
-
Material Testing: Ideal for evaluating the hardness of different plastic materials, the HBD 100-0 helps determine their suitability for specific applications, such as automotive parts, packaging, or consumer goods.
-
Quality Control: In production environments, the HBD 100-0 is used to check the hardness of plastic components, ensuring they meet the required specifications and standards for durability and performance.
-
Research & Development: In R&D, it aids in the development of new plastic formulations by providing accurate hardness measurements, supporting material innovation and improvement.
-
Product Lifecycle Testing: The HBD 100-0 helps assess how plastics will perform under stress or aging conditions, offering valuable data for products exposed to wear and tear.
