Specifications:
- Material thickness pulse-echo [Max] (mm): 200 mm
- Material thickness pulse-echo [Min] (mm): 1.5 mm
- Measuring range pulse-echo: 1.5 mm – 200 mm
- Readability material thickness [d] (mm): 0.1 mm
- Tolerance (% of [Max]): 0.5%
- Units: mm, inch
- Speed of sound [Max] (m/s): 9999 m/s
- Speed of sound [Min] (m/s): 500 m/s
- Speed of sound: 500 m/s – 9999 m/s
- Measuring head measuring frequency: 5 MHz
- Battery: 4×1.5 V AA
- Material housing: plastic
- Dimensions completely mounted (W×D×H): 161×69×32 mm
- Cable length: 0.9 m
Applications:
- Metal Thickness Measurement – Accurately measures the thickness of metal sheets, pipes, and plates.
- Plastic & Rubber Inspection – Determines the thickness of plastic films, rubber components, and synthetic materials.
- Glass & Ceramic Testing – Evaluates the uniformity of glass panes and ceramic products.
- Automotive Industry – Assesses coating thickness and material integrity in vehicle components.
- Aerospace & Aviation – Ensures precise measurement of critical aircraft materials.
- Shipbuilding & Marine Applications – Checks corrosion levels in ship hulls and metal structures.
- Construction & Engineering – Verifies material thickness for structural safety and compliance.
- Pipeline & Tank Inspection – Detects wear and corrosion in industrial pipelines and storage tanks.
- Electronics & Semiconductor Industry – Measures the thickness of circuit boards and electronic components.
- Quality Control & Manufacturing – Ensures products meet required thickness standards in various industries.
