Features:
- 20,000 lb Capacity per pad
- Portable Wheel Weigher
- Low Profile Platform Size- Only 1.3 inches / 34 mm High
- Lightweight Urethane Ramps
- Includes two Rechargeable 3.7V Lithium Ion Battery (18650)
- Includes Power Adapter (5V DC)
- Two Built in Ramped Ends
- In-Motion and Static Weighing
- IP67 Rated
- Zigbee Wireless Capabilities
- Built-in steel wheels for portability
- LCD Display with Backlight
TXDi-710FN Specifications:
- Available in 1, 2, 3, 4, 5, or 6 pads
- Capacity & Readability (lb): 20,000lb/20lb
- Capacity & Readability (kg): 10,000kg/10kg
- Resolution: 1/1,500
- Display type: LCD (Liquid Crystal Display)
- Keypad: On/off, Zero, Sum, Backlight
- In-Motion Speed: Up to 6 miles per hour / 10 kilometers per hour
- Operating Distance: TXI-500F Wireless Indicator – Approx 40 m / 131 ft
- Safe Overload: 150% of rated capacity
- Operating temperature (℉/℃): 14F ~ 104 / -10 ~ 40
- Power: 3.7V Lithium Ion Battery (18650)
- Battery Life: 50Hrs (Max. 120Hrs)
- Platform Dimensions (in/mm) (W x D x H): 33.3 x 28.7 x 1.9 / 845 x 730 x 49
- Product Dimensions (in/mm) (W x D x H): 27.6 x 19.7 x 1.3 / 700 x 500 x 34
- Product Weight (lb/kg): 50.3/22.8
- Ramp Weight (lb/kg): 3.5/1.6
- Warranty: Two years
