TXDi-710FN Wheel Weigher 20,000 lb x 20 lb

$2,499.00$14,994.00

Free Shipping

In Stock

Prime USA Scales TXDi-710FN wireless wheel weigher scale comes in 27″ x 19″ x 1.3″ per pad. Each pad has a capacity of 20,000 lb and a 20 lb readability. This system can be set-up for 1 pad, 2 pads, 3 pads, 4 pads, 5 pads, 6 pads or more. Using our optional TXI-500F wireless display can connect up to 16 pads at one time. Great for weighing RVs, pick-ups, trailers, trucks, dump trucks,  tractor trailers, and many other types of vehicles. The TXDi can be used for static weighing (stop and go) or can be used  for in-motion driving across the scale at 6 mph. Package arrives calibrated, ready for use, & Free shipping.

Features:

  • 20,000 lb Capacity per pad
  • Portable Wheel Weigher
  • Low Profile Platform Size- Only 1.3 inches / 34 mm High
  • Lightweight Urethane Ramps
  • Includes two Rechargeable 3.7V Lithium Ion Battery (18650)
  • Includes Power Adapter (5V DC)
  • Two Built in Ramped Ends
  • In-Motion and Static Weighing
  • IP67 Rated
  • Zigbee Wireless Capabilities
  • Built-in steel wheels for portability
  • LCD Display with Backlight

TXDi-710FN Specifications:

  • Available in 1, 2, 3, 4, 5, or 6 pads
  • Capacity & Readability (lb): 20,000lb/20lb
  • Capacity & Readability (kg): 10,000kg/10kg
  • Resolution: 1/1,500
  • Display type: LCD (Liquid Crystal Display)
  • Keypad: On/off, Zero, Sum, Backlight
  • In-Motion Speed: Up to 6 miles per hour / 10 kilometers per hour
  • Operating Distance: TXI-500F Wireless Indicator – Approx 40 m / 131 ft
  • Safe Overload: 150% of rated capacity
  • Operating temperature (℉/℃): 14F ~ 104 / -10 ~ 40
  • Power: 3.7V Lithium Ion Battery (18650)
  • Battery Life: 50Hrs (Max. 120Hrs)
  • Platform Dimensions (in/mm) (W x D x H): 33.3 x 28.7 x 1.9 / 845 x 730 x 49
  • Product Dimensions (in/mm) (W x D x H): 27.6 x 19.7 x 1.3 / 700 x 500 x 34
  • Product Weight (lb/kg): 50.3/22.8
  • Ramp Weight (lb/kg): 3.5/1.6
  • Warranty: Two years
