Features:
Hardware
- Color-coded keys facilitate quick recognition of the most frequently used buttons
- RS-232 interface is available to provide speedy connection to computers
- Rugged construction stands up to industrial use
- Built in printer can print weight, QR codes, bar codes and labels in numerous languages
Software
- Zero-tracking feature ensures display returns to zero reading
- Parts counting optimization automatically refines piece weight as parts are added
- Checkweighing with audible alarm
- External calibration allows for verification and adjustment with weights
- Quick and easy configuration using the keypad
- User-selectable scale division
Display
- Vivid, backlit LCD easily visible in any lighting conditions
- Programmable backlight can be set to “always on,” “always off” or “light only when weighing”
Power
- Rechargeable battery included for operation almost anywhere
- Programmable auto power-off to save energy
Specifications:
- Model: AE 504
- Capacity Range: Selectable
- Resolution: 1:60,000
- Excitation Voltage: 5VDC
- Loadcells: 8
- Sensitivity: 0.02uv/e
- Zero Range: +/- 20 %
- Signal Range: – 20mV – 20mV
- Weighing Units: kg, g, lb, oz
- Stabilization Time (sec): 2
- PLU memories: 1006
- Interface: RS-232
- Calibration: External calibration
- Display: Backlit LCD with 0.87″ and 0.63” / 22mm -high digits and 16mm -high digits
- Power Supply: 12VDC 3A adapter / Internal rechargeable battery
- Operating Temperature: 0° to 40°C / 32° to 104°F
- Housing: ABS plastic
- Overall Dim.: 11.8”x4.9”x6.7” / 300x170x125mm (wxdxh)
- Net Weight: 6.2lb / 2.8kg
