US-AW2416-20K “AirWeigh” Plane Scale 20,000 lb

$3,595.00

Free Shipping | Manufactured by USA Measurements | Ships Las Vegas, NV

USA Measurements US-AW2416-20K “AirWeigh” scale to weigh small to medium airplanes, aircrafts, and jets. The US-AW2416-20K features a pad size of 24″x16″ with built in ramped ends. Each pad has an overall height of 2.2″. This makes for easy on / off to weigh planes quickly. Our “AirWeigh” comes in a 3 pads set with digital indicator. The digital display can read individual weights and total gross weight. WATCH OUR VIDEO BELOW.

Have Questions? Call us now: (800) 917-7205

My Personal Guarantee:

• easy to setup
• easy to use
• easy replacement parts
• easy calibration/phone support

• easy warranty support
• 30 day money back guarantee
• lowest price guarantee

CALL NOW 800-917-7205

The US-AW2416-20K has a capacity of 7,000 lb per pad and a gross capacity of 20,000 lb. The scale has an accuracy and readability of 5 lb. Each US-AW2416-20K series pad is portable weighing 45 lb.  Each pad is constructed with strengthened aluminum steel. The digital display operates with AC power adapter or the built in rechargeable battery up to 100 hours. The US-M5 (digital display) features an RS-232 port to connect with a PC,  three stainless steel braided cables, and printer. Our included receipt printer allows the user to print weight, date, and time.

***Please note: Our aircraft scale package includes certificates of calibration for records. Our US-AW2416-20K satisfies all FAA requirements for 12 months (1 Year). We offer recertification services at our shop, which cost $30 per pad. We recommend calibration and inspection every year, but all our scales will hold calibration for many years.

Specifications:

  • Material: strengthened Aluminum
  • Overload Protection: 200%
  • Indicator: US-M5 with pelican protective case
  • Power: AC/DC, built-in rechargeable battery (100 hrs)
  • Cable Length: 33 ft
  • Warranty: 5 Year on Frame
  • Warranty: 2 Year on Electronics

Features:

  • Capacity: 20,000 lb
  • Readability/Accuracy: 5 lb
  • Size: 24″ x 16″ x 2.2″
  • Load Cells: 6 per pad
  • Indicator Power: AC/DC, built-in rechargeable battery (100 hrs)
  • Portable, low profile and heavy duty construction
  • Easily weighs large vehicles such as trucks, vans, tankers and trailers
  • Interlocking skid resistance ramps
  • Two handles and two wheels for easy carry and moving
  • Easy to use; user can operator and weigh single-handedly
  • Includes indicator suitcase for protection and portability
  • Built-in printer that prints weight of each pad and accumulates gross weight with time / date

Indicator Features:

  • US-M5 indicator with LCD display with briefcase
  • Included printer
  • 1″ Tall backlit display
  • Rechargeable battery (up to 100 hrs)
  • Metal casing
  • AC adapter included
  • Weighing units: (lb/kg)
  • Gross/Tare/Zero
  • Multiple Hold functions
  • Accumulation weighing
  • Splash proof  keyboard and display
  • Connects to a remote display
