Features:
- Heavy duty stainless steel construction
- NTEP Washdown lift up scale
- Built for pit or above ground use
- Stainless steel gas spring shocks
- Lift up diamond plated top platform (or smooth top)
- Easy lifting of heavy duty deck for washdown cleaning
- Includes a NEMA 4 washdown indicator with lb/kg
- measurements and rechargeable battery option
- Built-in RS-232 communication port
- 20ā long heavy duty metal shielded cable for indicator
- Factory Calibrated
- 200% Overload Protection
Indicator Features:
- OP-900SS NTEP indicator with LED or LCD display
- 1″ Tall backlit display
- Optional Rechargeable battery (up to 100 hrs)
- Stainless steel washdown NEMA 4X casing
- AC adapterĀ included
- Weighing units: (LED:kg/lb) ( LCD:lb/kg/g/oz/lb:oz)
- Gross/Tare/Pre-Set Tare/Zero
- Multiple Hold functions
- Count weighing
- Accumulation weighing
- Overload / Underload alarm
- Splash proofĀ keyboard and display
- Connects to a remote display and printer
- NTEP approved for 5,000 divisions
- Displays up to 50,000 graduations
- Full Duplex RS-232 Serial Port
Specifications:
- Material: Washdown Stainless Steel
- Overload Protection: 200%
- IP Rating: IP65 to IP69K
- Indicator: OP-900, 8200REPEL
- Power: AC/DC,
- Capacity: 2,000 lbs – 10,000 lbs
- Cable Length: 20 ft
- Warranty: 2 year on electronics
- Warranty: 5 years on Frame
Resources:
Options:Ā
- Thermal Printer
- Label Printer
- Indoor Remote Display 3ā³ Digits
- Indoor Remote Display 5ā³ Digits
- Outdoor Remote Display 6ā³ Digits
- Software
- Indicator Stand (stainless steel)
- Heavy Duty Indicator StandĀ
- Certificate of CalibrationĀ
- Indicator with 4-20ma Output
- Indicator with Setpoint / Relay Function
