How RCS Works:
An oil pressure sensor is installed onto the hydraulic circuit of the forklift utilizing a T-coupling. The indicator in the cabin translates the measurement into a weight indication of the load on the forks.
The RCS is mainly used to simply check weight and avoid the overloading of lorries, warehouse racking and the forklift truck itself. Also suitable for rough applications.
- Markings on the forklift indicate the weight read-out point
- The load is lifted until just past the markings on the mast
- The load is lifted until just past the markings on the mast
- Then the load is lowered to the reference markings
- After 3 seconds the indicator shows the weight
System Package:
- Weighing Sensor
- Sealing Ring
- Indicator 2100 with 4 AA-Batteries & Mounting Bracket
- Lifting Height Reference Mark Stickers
- Mounting and Calibration Instructions
- Operating Manual
Standard Specifications:
- Capacities: 5,000, 10,000 or 20,000 lb
- 2% of System Capacity at Centered Load
- Protection Class: NEMA 4 / IP65
- Display LCD, Digital Display Height 0.7″
- Protection Class: IP65
- Controls: 3 Function Keys, ON/OFF Key
- Power Supply: 6Vdc from 4 AA-Batteries
- Battery Cycle Time: 6 Months
- Auto Shut Off: After 3 Minutes of Non-Use
Benefits:
- 2% Accuracy Hydraulic Scale
- User Friendly Display
- Easy Calibration Due
- Overload Protection
- Suitable for Light Duty to Medium Applications
Graduation:
- 10 lb at 5,000 lb
- 20 lb at 10,000 lb
- 50 lb at 20,000 lb
