Package Features:
- (4) Shear Beam Load Cells 5,000 lb each
- Each Load Cell 100% overload protection
- Includes all mounting hardware to install scale kit
- Can be set-up for capacities from 500 lb to 20,000 lb
- Low Profile Design for Easy Installation
- Commonly used for scale repairs, tanks, hoppers, & silo’s
- Concrete Mounting Load Cells to Fix into Place
- More Load Cells can be added if needed
Scale Kit Includes:
- (4) Alloy Steel US-AS5K Load Cells (Total capacity 20,000 lb)
- (1) Bright LCD US-6011SS Indicator with wall-mount
- (1) 4 way US-JB4MS junction box
- (4) Concrete Mounting Leveling Feet
- All Necessary Mounting Hardware
- 20’ Long Stainless Steel Shielded Cable
Indicator Features:
- Stainless Steel enclosure
- Units: lb, kg, oz, lb:oz, g
- Gross/Tare/Pre-Set Tare/Zero
- Count Weighing Function
- 1” LCD display with backlight
- Energy Saving mode
- Multiple Hold functions
- Accumulation weighing
- Overload / Underload alarm
- Allows for Date & Time Set-up
- Full 100% Manual Tare
- Automatic error warning alarm
- Splash proof keyboard and display
- RS-232 Port for remote display
- RS-232 Port for Printers or PC
- Displays up to 50,000 graduations
- Includes Indicator Mounting Bracket
- Operates on 110V AC adapter (included)
- Powers up to (6) 350 ohm load cells
Indicator Package Includes:Â
- (1) US-6011SS Digital LCD Indicator
- (1) Built in Rechargeable Battery (100 hour life)
- (1) AC Power Adapter
- (1) 20′ Stainless Steel Home Run Cable
- (1) Owner’s Manual
- Stainless Steel Mounting Bracket
Options:Â
- Thermal Printer
- Label Printer
- Indoor Remote Display 3″ Digits
- Indoor Remote Display 5″ Digits
- Outdoor Remote Display 6″ Digits
- Software
- Indicator Stand (stainless steel)
- Heavy Duty Indicator StandÂ
- Certificate of CalibrationÂ
- Intrinsically Safe Indicator
- Indicator with 4-20ma Output
- Indicator with Setpoint / Relay Function
